Power Adapter Current Protection Slow Blow Box Fuse NTS T3.15A 300V With CQC UL TUV

Name: Power Adapter Current Protection Slow Blow Box Fuse NTS T315A 300V With CQC UL TUV
Brand: AMPFORT
Price: 0.04 USD

Wholesale Power Adapter Current Protection Slow Blow Box Fuse NTS T3.15A 300V With CQC UL TUV from china suppliers

Brand Name : AMPFORT

Model Number : NTS T3.15A 300V

Certification : CQC UL TUV

Place of Origin : Dongguan,Guangdong,China

MOQ : 10000PCS

Price : 0.04~0.06 USD/PC

Payment Terms : T/T, Western Union

Supply Ability : 100KKPCS Per month

Delivery Time : 10 workdays

Packaging Details : Bulk or tape

Name : Box Fuse

Speed : Slow Blow T

Rated voltage : 300V

Current : 3.15A

Package : Bulk,short lead,3.5mm

Color : Brown or black

Contact Now

Power Adapter Current Protection Slow Blow Box Fuse NTS T3.15A 300V With CQC UL TUV

Description Of The Slow Blow Box Fuse

A miniature fuse is a relatively small fuse. With the continuous development of domestic technology, it is also required for many high-end and small products. Now there are two common fuses on the market: miniature round fuses and miniature square fuses.A miniature fuse is an electronic component suitable for inserting or soldering into the corresponding electrical appliance. It has small size, high sensitivity, and rapid response. In some circuits where the product space is not very large, it can better reflect its advantages. .

Power Adapter Current Protection Slow Blow Box Fuse NTS T3.15A 300V With CQC UL TUV

Application Of The Slow Blow Box Fuse

Miniature square fuses can be used in set-top boxes, switching power supplies, power adapters, LCD TVs, computers, communication products, telephones, household appliances, various instruments and various electronic and electrical components.

Part Numbering Of The Slow Blow Box Fuse

Part No.	Ampere Rating	Voltage Rating	Max Voltage Drop (mv)	I2TMelting Integral(A2.S)	Agency Approvals
Part No.	Ampere Rating	Voltage Rating	Max Voltage Drop (mv)	I2TMelting Integral(A2.S)	cRU us	TUV	c UL us	CQC	UL
NTS0050A	50mA	300V	1600	0.015	●	○	●	○	○
NTS0063A	63mA	300V	1600	0.016	●	○	●	○	○
NTS0080A	80mA	300V	1500	0.017	●	○	●	○	○
NTS0100A	100mA	300V	1500	0.02	●	○	●	○	○
NTS0125A	125mA	300V	760	0.10	●	○	●	○	○
NTS0160A	160mA	300V	500	0.15	●	●	●	○	○
NTS0200A	200mA	300V	260	0.21	●	●	●	○	○
NTS0250A	250mA	300V	240	0.48	●	●	●	○	○
NTS0315A	315mA	300V	220	0.78	●	●	●	○	○
NTS0400A	400mA	300V	200	1.22	●	●	●	○	○
NTS0500A	500mA	300V	190	2.11	●	●	●	○	○
NTS0630A	630mA	300V	180	2.88	●	●	●	○	○
NTS0800A	800mA	300V	160	3.92	●	●	●	○	○
NTS1100A	1A	300V	140	5.77	●	●	●	●	○
NTS1125A	1.25A	300V	130	8.34	●	●	●	○	○
NTS1160A	1.6A	300V	120	13.60	●	●	●	○	○
NTS1200A	2A	300V	100	26	●	●	●	●	○
NTS1250A	2.5A	300V	100	42	●	●	●	○	○
NTS1300A	3A	300V	100	45	●	●	●	○	○
NTS1315A	3.15A	300V	100	90	●	●	●	●	○
NTS1350A	3.5A	300V	100	100	●	●	●	○	○
NTS1400A	4A	300V	100	120	●	●	●	○	○
NTS1500A	5A	300V	100	170	●	●	●	●	○
NTS1630A	6.3A	300V	100	290	●	●	●	●	○
NTS1800A	8A	300V	100	320	○	●	●	○	○
NTS2100A	10A	300V	95	450	○	●	●	○	○
NTS2120A	12A	300V	95	460	○	●	●	○	○
NTS2150A	15A	300V	85	480	○	●	●	○	○
NTS2160A	16A	300V	85	515	○	●	●	○	○
NTS2200A	20A	300V	85	960	○	●	●	○	○

Power Adapter Current Protection Slow Blow Box Fuse NTS T3.15A 300V With CQC UL TUV
